Measurement Range: -0.1…0 to 0.01…100 MPa (optional within the full scale range)Stability: ±0.1%FS/year (typical), ±0.2%FS/year (maximum)Zero Drift: ±0.03%FS/°C (≤100 kPa), ±0.02%FS/°C (>100 kPa)Span Drift: ±0.03%FS/°C (≤100 kPa), ±0.02%FS/°C (>100 kPa)Medium Temperature: -30～85°C / -30～150°CStorage Temperature: -40°C～120°CPower Supply: 9～28 VDC (wide voltage supply)Output Signals: 4～20 mA, 0-5 V, 0-10 V, RS485, HSRT, etc.Load Resistance: ≤(U-15)/0.02 Ω, ≤(U-15)/0.02 Ω, >5k Process...
Send Inquiry
Measurement Range: -0.1…0 to 0.01…100 MPaOverload: 1.5 times full scale pressurePressure Type: Gauge pressure, absolute pressure, or negative pressureAccuracy: ±0.25%FS (typical), ±0.5%FS (maximum) (diffused silicon) ±0.5%FS (typical), ±1%FS (maximum) (ceramic piezoresistive)Stability: ±0.1%FS/year (typical), ±0.2%FS/year (maximum)Zero Drift: ±0.03%FS/°C (≤100 kPa), ±0.02%FS/°C (>100 kPa)Span Drift: ±0.03%FS/°C (≤100 kPa), ±0.0...
Send Inquiry
Measuring Range: ±7KPa~2.5KPa~7MPaOverload: 10 times full-scale pressureAccuracy: ±0.1%FS, ±0.2%FSStability: ±0.05%FS/year, ±0.2%FS/yearZero Drift：≤100KPa: ±0.03%FS/°C ＞100KPa: ±0.02%FS/°CSpan Drift：≤100KPa: ±0.03%FS/°C ＞100KPa: ±0.02%FS/°CMedium Temperature: -30°C～125°CStorage Temperature: -40°C～120°CPower Supply: 12～36VDC (intrinsically safe type...
Send Inquiry
Medium: Gas, liquid (non-corrosive to stainless steel)Range: -0.1-100 MPa (optional within the full scale range)Overload: 1.5 times full scale pressurePressure Type: Gauge pressure, absolute pressure, negative pressureAccuracy: 0.1%FSStability: ±0.1%FS/yearZero Drift: ±0.03%FS/°C (≤100 kPa), ±0.02%FS/°C (>100 kPa)Span Drift: ±0.03%FS/°C (≤100 kPa), ±0.02%FS/°C (>100 kPa)Compensation Temperature: -10～80°CMedium Temperature: -20°C～80°CStorage Temperature: -40°C～85°CPower Supply: 24VDC (9...
Send Inquiry
Measurement Range: G: 0…0.15 to 41370 kPa, A: 0…6.2 to 6890 kPaOutput Signal: 4~20mA output superimposed with HART® protocol digital signal (two-wire system)Power Supply: External power supply 24VDC (power range 12V~45V)Installation: Explosion-proof type ExdⅡCT6, intrinsically safe type ExiaⅡCT6Migration Characteristics: After positive/negative migration, the upper and lower limits of the range shall not exceed the range limit. At the minimum range, the maximum positive migration...
Send Inquiry
Medium: Pure gasMeasurement Range: -5-0-5 kPa (optional within the full scale range)Overload: 1.5 times full scale pressureAccuracy: 0.5%FSStability: ±0.1%FS/year (typical)Zero Drift: ±0.03%FS/°C (≤100 kPa), ±0.02%FS/°C (>100 kPa)Span Drift: ±0.03%FS/°C (≤100 kPa), ±0.02%FS/°C (>100 kPa)Medium Temperature: -30～85°CStorage Temperature: -40°C～120°CPower Supply: 24VDC (12～36 VDC wide voltage) (intrinsically safe type powered via safety barrier)Output Signals: 4～20mA, 0-5V, 0-10V, RS485 co...
Send Inquiry
Measuring Range: 0～1KPa～100Kpa; 0～6KPa～2.5MPa Overload: ≤ 10 times the rated pressure Accuracy: ±0.25%FS (typical), ±0.5%FS (maximum) Medium Temperature: -30-85℃, -30-150℃ Storage Temperature: -40℃～120℃ Power Supply: 24 VDC (12～36 VDC) (intrinsically safe type powered via safety barrier) Output Signal: 4～20mA, 0/1～5/10V, RS485 (non-standard customization)Load resistance: ≤ (U-15)/0.02 Ω, ≤ (U-15)/0.02 Ω,>5kLoad Resistance: ≤ (U-15)/0.02Ω, ≤ (U-1...
Send Inquiry
Measuring Range: Gauge pressure -0.1…0～0.01…100MPaOverload: 1.5 times full-scale pressure or 110MPa (whichever is smaller)Alarm Contacts: 1～5 pointsDisplay Range: -1999～9999Load Capacity: 240V/3A (AC) or 30V/5A (DC)Contact Life: 100,000 timesAccuracy: ±0.25%FS (typical), ±0.5%FS (maximum)Stability: ±0.1%FS/year (typical), ±0.2%FS/year (maximum)Zero Drift: ±0.03%FS/℃ (≤100kPa)  ...
Send Inquiry
Measuring Range: Gauge pressure -0.1…0～0.01…100MPaOverload: 1.5 times full-scale pressure or 110MPa (whichever is smaller)Alarm Contacts: 1～5 pointsDisplay Range: -1999～9999Load Capacity: 240V/3A (AC) or 30V/5A (DC)Contact Life: 100,000 timesAccuracy: ±0.25%FS (typical), ±0.5%FS (maximum)Stability: ±0.1%FS/year (typical), ±0.2%FS/year (maximum)Zero Drift: ±0.03%FS/℃ (≤100kPa)  ...
Send Inquiry
Measuring Range: -0.1…0～0.01…6MPa (optional within the range)Overload Pressure: 1.5 times full-scale pressureAlarm Contacts: 1-5 points selectable (2 points standard)Display Range: -1999～9999Load Capacity: 240V/3A (AC) or 30V/5A (DC)Contact Life: 100,000 timesAccuracy: ±0.25%FS (range≥100kPa) ±0.5%FS (range<100kPa)Stability: ±0.1%FS/yearZero Drift: ±0.03%FS/℃ (≤100kPa) &nbs...
Send Inquiry
Measuring Range: -0.1…0～0.01…6MPa (optional within the range)Overload Pressure: 1.5 times full-scale pressureAlarm Contacts: 1-5 points selectable (2 points standard)Display Range: -1999～9999Load Capacity: 240V/3A (AC) or 30V/5A (DC)Contact Life: 100,000 timesAccuracy: ±0.25%FS (range≥100kPa) ±0.5%FS (range<100kPa)Stability: ±0.1%FS/yearZero Drift: ±0.03%FS/℃ (≤100kPa) &nbs...
