Measuring Range: Gauge pressure -0.1…0～0.01…100MPa

Overload: 1.5 times full-scale pressure or 110MPa (whichever is smaller)

Alarm Contacts: 1～5 points

Display Range: -1999～9999

Load Capacity: 240V/3A (AC) or 30V/5A (DC)

Contact Life: 100,000 times

Accuracy: ±0.25%FS (typical), ±0.5%FS (maximum)

Stability: ±0.1%FS/year (typical), ±0.2%FS/year (maximum)

Zero Drift:  ±0.03%FS/℃ (≤100kPa)

                    ±0.02%FS/℃ (>100kPa)

Span Drift:  ±0.03%FS/℃ (≤100kPa)

                    ±0.02%FS/℃ (>100kPa)

Medium Temperature: -30℃～85℃

Storage Temperature: -40℃～85℃

Power Supply: 24VDC or 220VAC

Output Signal: Analog: 4～20mADC, 0～10/20mADC or 0/1～5VDC

                          Digital: RS485

Load Resistance: ≤ (U-15)/0.02Ω, ≤ (U-15)/0.02Ω, ＞5k

Process Connection: M20×1.5 External thread

                                   M27×2 external thread

                                   Clamp connection (other types can be customized)

Shell Protection: IP65 for both cable and connector connections
