Measuring Range: 0～1KPa～100Kpa; 0～6KPa～2.5MPa
Overload: ≤ 10 times the rated pressure
Accuracy: ±0.25%FS (typical), ±0.5%FS (maximum)
Medium Temperature: -30-85℃, -30-150℃
Storage Temperature: -40℃～120℃
Power Supply: 24 VDC (12～36 VDC) (intrinsically safe type powered via safety barrier)
Output Signal: 4～20mA, 0/1～5/10V, RS485 (non-standard customization)

Load resistance: ≤ (U-15)/0.02 Ω, ≤ (U-15)/0.02 Ω,>5k

Load Resistance: ≤ (U-15)/0.02Ω, ≤ (U-15)/0.02Ω, ＞5k
Process Connection: φ8 air nozzle, G1/2, 1/2npt, M20×1.5 External thread (other types can be customized)
Shell Protection: Both cable and connector connections are IP65
Stability: ≤0.2%FS/year
