Operating Pressure: 6000 PSI (413 bar), up to 10000 PSI (689 bar)

Operating Temperature:

                                         PTFE Packing: -38°C to 180°C (-100°F to 356°F)

                                        PPL Packing: -38°C to 280°C (-100°F to 536°F)

                                        Graphite Packing:  -24°C to 480°C (-75°F to 896°F)

Connection Port: 1/2 NPT (F)

Drain Port: 1/4 NPT (F)

Flow Path Aperture DN: 4.0 mm (0.157 in.)

Body Materials: 316 Stainless Steel, Hastelloy, Monel, and other special materials
