Working pressure: 6000 PSI (413 bar), up to 10000 PSI (689 bar)

Working temperature:

                                      PTFE packing: -38°C to 180°C (-100°F to 356°F)

                                      PPL packing: -38°C to 280°C (-100°F to 536°F)

                                      Graphite packing: -24°C to 480°C (-75°F to 896°F)

Connection port: 1/2 NPT (FXM)

Flow channel aperture DN: 4.0 mm (0.157 in.)

Valve body materials: 316 Stainless Steel, Hastelloy, Monel alloy, and other special materials
