Case Material: Aluminum Oxide
Connection Material: Stainless Steel
Repeatability (Reference Temperature 25℃): ±2%FS
Protection Class (EN60529): IP65
Process Connection: G1/4" Internal Thread
Measuring Element: Piston
Sealing Materials:

                             Piston: PTFE (Dynamic), NBR or Fluororubber (Static)
                             Electrical Interface: Harting Connector DIN 43650
Temperature Range:

                             Ambient Temperature: -20~80℃

                             Medium Temperature: -20~80℃

Switch Type: One SPDT
Deadband: <20% of High Alarm Value
Switch Contact Rating: 3A 250VAC or 4A 30VDC
Maximum Pressure Resistance: 600bar
Setpoint Adjustment: Adjustable Knob with Scale
Service Life: >1×10⁶ Pressure Cycles
Electrical Contact: Silver Alloy
Switching Frequency:

                                 Non-energized: Max. 400 Cycles/Minute

                                 Energized: Max. 30 Cycles/Minute
